Deposition of dielectric thin films RF Magnetron Sputtering MM 731: Experiments in advanced materials processing (Lab.)

Document Content and Description Below

Deposition of dielectric thin films RF Magnetron Sputtering MM 731: Experiments in advanced materials processing (Lab.)RF (radio frequency) sputter deposition • Good for insulating materials be ... cause, positive charge (Ar+) build up on the cathode (target) in DC sputtering systems. Alternating potential can avoid charge buildup • When frequencies less than 50kHz, both electrons and ions can follow the switching of the anode and cathode, basically DC sputtering of both surfaces. • When frequencies well above 50kHz, ions (heavy) can no longer follow the switching, and electrons can neutralize positive charge buildup on each electrode during each half cycle. • As now electrons gain energy directly from RF powder (no need of secondary electrons to maintain plasma), and oscillating electrons are more efficient to ionize the gas, RF sputter is capable of running in lower pressure (1-15 mTorr), so fewer gas collisions and more line of sight deposition. 13.56MHz RF source Switch polarities before the target surface saturates with ions. [Show More]

Last updated: 3 years ago

Preview 1 out of 11 pages
